LEDONE ECO CONNECTED

Instructions for the LEDONE mandatory beacon

See the Spanish version

See the French version

See the Portuguese version

See the German version

Download the LEDONE App

*Available only for customers of our connected emergency light.

Immediately notify your insurance provider or any emergency services.

DOWNLOAD APP:

Procedure

  • In case of an incident, follow traffic regulations and stop your vehicle in a safe location.
  • Activate the beacon and place it on the vehicle to immediately alert others of your position on the road.
  • Occupants must wear a reflective vest, exit the vehicle on the side opposite to traffic, and wait in a safe location. If it is not safe to leave the vehicle, stay inside with the seatbelt fastened (Article 130 RGC).
Comprar

Doble sistema de fijación

Magnética y adesiva

Double fixation system

Magnetic and adhesive

Use and maintenance

  • Store the beacon in an accessible place, such as the glove compartment or the motorcycle's trunk
  • Use LEDONE V16® to be seen and located. Avoid using this device while in motion, as vibrations may cause it to fall.
  • It works with a 9-volt alkaline battery 6LR61. Verify the correct type and voltage when replacing it. Do not disassemble the device. Replace the battery when the light intensity decreases significantly.
  • Install and use the beacon at a minimum distance of 20 cm from your body.

Geolocalización

Evita otros accidentes

Visible a 1km de distancia

Luces de alta eficiencia luminosa

Geolocation

Avoid other accidents

Visible from a distance of 1 km.

High luminous efficiency lights

Warranty

  • Coverage: LEDONE V16® is guaranteed against manufacturing defects in accordance with the applicable legislation.
  • Requirements: The purchase receipt or invoice must be presented to use the warranty.
  • Procedure: Contact your distributor directly or visit the website for more information.
Comprar

Materiales 100% reciclados

La primera y única luz de emergencia del mercado reciclada

100% recycled materials

The first and only recycled emergency light on the market.

Precautions

  • Use: It is not a toy and should not be used by children or inexperienced individuals unless supervised.
  • Magnetic base: Keep away from sources that emit or receive sensitive magnetic radiation, and from pacemakers.
  • Ingestion: In case of accidental ingestion, it may cause serious injuries.
  • Heating: It is normal for the battery to heat up during use due to the high energy demand.
  • Do not handle the inside of the battery compartment during use. The battery should only be handled or replaced when the device is turned off and at least 10 minutes have passed since its last use. There is a potential risk of explosion if replaced with an incorrect type.
  • Disposal: Dispose of the battery at an authorized recycling point. If the device breaks, dispose of it at a proper recycling facility.

Para todo tipo de vehículos

Visible en coches con barras laterales de techo

For all types of vehicles

Visible on cars with roof sidebars

Technical specifications

Connection and flash specifications

Flash sequence:

  • First 100 seconds: 2 flashes.
  • Connection with the DGT: 1 flash for approximately 1.5 hours.
  • Afterwards: It returns to 2 flashes until it turns off, with an additional duration of approximately 1 hour.

Light sources:

  • They are not replaceable by the user.
  • They can only be replaced by the manufacturer, its technical service, or a qualified person.

Frequency bands of the device:

  • NB-IoT FDD Band 8: TX 880 MHz a 915 MHz / RX 925 MHz a 960 MHz.
  • NB-IoT FDD Band 20: TX 832 MHz a 862 MHz / RX 791 MHz a 821 MHz.
  • NB-IoT FDD Band 28: TX 703 MHz a 748 MHz / RX 758 MHz a 803 MHz.
  • GPS L1 & GLONASS G1 & BDS B1: 1559 MHz – 1610 MHz.

Maximum radiofrequency power:

  • NB-IoT FDD Band 8: 23.15 dBm.
  • NB-IoT FDD Band 20: 25.44 dBm.
  • NB-IoT FDD Band 28: 23.34 dBm.

Compatibility and regulations

Compatible functions: NB-IoT/GNSS.

Conformity: Complies with European Union legislation (Radio Equipment Directive: 2014/53/EU).

Applied standards:

IN IEC 55015: 2019 / IN IEC 61000-3-2: 2019+A1: 2021 / IN 61000-3-3: 2013+A2: 2021 / IN 61547: 2009 / ETSI IN 301 489-1 V2.2.3: 2019 / ETSI IN 301 489-19 V2.2.0: 2020 / ETSI IN 301 489-52 V1.2.1: 2021 / ETSI IN 301 908-1 V13.1.1: 2019 / ETSI IN 301 908-13 V13.1.1: 2019 / ETSI IN 303 413 V1.1.1: 2017 / IN 50385: 2017 / IN 62311: 2020 / IN 62368-1: 2014+A11: 2017



Model PFLOV16

Dimensions: 106x68x68cm

Weight: 161 gr

Operating temperature: Entre -10ªC y 50ºC

Wind resistance: 180 Pa

Ingress protection: IP54.

Activation: Manual

Battery type: Pila 9V (6LR61)

DECLARATION OF CONFORMITY



LEDONE V16® is a flashing emergency beacon in yellow, with autonomous operation powered by a 9-volt alkaline battery type 6LR61. ERUM VIAL, S.L. CERTIFIES that this equipment complies with the requirements of the applicable European Directives and harmonized regulations, as well as the regulations listed below. The design and construction of this equipment have taken into account these Directives and regulations, according to tests conducted by the accredited laboratories LCOE (Official Central Electrotechnical Laboratory).

APPROVED PRODUCT

ERUM VIAL, S.L. certifies that the equipment is approved by the LCOE (Official Central Electrotechnical Laboratory) with the approval number LCOE 2023010084G1. It complies with Order PCI/810/2018, which modifies Annex XI of the General Vehicle Regulations, and Instruction 18/V-132 of the Directorate General of Traffic. The SIM card expiration date is located on the base of the beacon. Designed and manufactured in Spain and distributed by Erum Vial, S.L.

For more information, please contact us by calling (+34) 919 030 292 or through the website www.erumvial.com.

Use of the beacon:

  • Activate: Hold the base and turn the dome to the left.
  • Deactivate: Hold the base and turn the dome to the right.

BATTERY REPLACEMENT

  • Hold the beacon and turn the dome to the right until it detaches.
  • Always use 9V 6LR61 alkaline batteries.
  •  Remove the used battery and insert the new one according to the indicated polarity.
  • Reattach the dome by aligning the slot with the inner tab and turn it to the left.

Recommendations:

  • Check the battery condition periodically, although its warranty is 2 years without use.

Additional functions:

  • LEDONE V16® complies with regulation 1030/2022, both in lighting and in the anonymous sending of the location to the DGT without having to use the application.
Preguntas frecuentes

Es una baliza luminosa de emergencia de alta calidad, diseño patentado, ligera, compacta y de fácil funcionamiento. Emite un intense destello de color amarillo auto visible en 360°. Su base magnética permite que su colocaci6n sobre el vehículo sea rápida y sencilla, además con el accesorio adhesivo permite su fijación en superficies plásticas. Este dispositivo cumple con los límites de exposición a la radiación establecidos en la CE para un entorno no controlado.

A día de hoy hay varias luces de emergencia que están homologadas por la DGT y que cumplen con todos los requisitos. Te dejamos la página de la DGT con las balizas homologadas: Dispositivos de preseñalización V16

La baliza LEDONE ECO Connected, antiguamente llamada PF Led ONE V16, fue de las primeras en estar homologadas por la DGT.

El precio medio de una luz de emergencia V16 homologada, es de 50€ la unidad en caso de comprarla por separado. El precio depende del diseño, la tecnología, así como los materiales con los que se fabrica. El precio de la luz de emergencia LEDONE ECO Connected es de 49,95€ la unidad, por separado.

Existen varias luces de emergencia que cumplen con todos los requisitos para estar homologadas y ser funcionales. La luz LEDONE ECO Connected, además de cumplir con todos los requisitos, es un dispositivo fabricado a partir de materiales reciclados, respetando así el medio ambiente. Además es la baliza más alta del mercado, mejorando la visibilidad en cualquier situación. Una opción ideal para mejorar la seguridad vial en carretera.

La luz de emergencia está diseñada para usar en los mismos casos que los triángulos de emergencia, es decir, en caso de accidente o avería en la carretera. El objetivo de este dispositivo es el de prevenir accidentes señalizando la situación del vehículo, alertando así al resto de vehículos, y a las autoridades en caso de ser necesario.

La geolocalización se activa únicamente cuando la baliza V16 está conectada y en funcionamiento. El objetivo de conocer la localización del vehículo es la de poder informar al resto de vehículos mediante los paneles de la carretera, así como poder enviar algún equipo de emergencia en caso de ser necesario.
